homelab

Middle-Earth Cluster homelab repository

A place for experimentation, fun and never-rending YAML files.

_{“Even the smallest server can run the mightiest workloads.”
— 🧙‍♂️ Gandalf, the homelabber wizard}

_{Built with viele ☕️ by
Josimar Silva.
|
Delivering greatness from the trenches of

Gondor.}

## Table of Contents - [Introduction](#introduction) - [Middle Earth Cluster](#middle-earth-cluster) - [Software](#software) - [Network](#network) - [Storage](#storage) - [Acknowledgements](#acknowledgements) - [References](#references) ## Introduction This repository contains the entire configuration of my Kubernetes-based homelab. It is managed using GitOps principles with FluxCD, Renovate and GitHub Actions. The goal of this project is to create a stable, reproducible and automated homelab environment for learning and experimentation. ## Middle Earth Cluster The heart of the homelab is a Kubernetes cluster named "Middle-Earth". This cluster is built on top of Talos OS and its Talos configuration is provisioned from a private repository. ### Server Rack The server rack is a custom-built 19" rack that houses all the hardware for the homelab. It includes the mini-PCs, switch, firewall, patch panel, NAS and UPS. ![server rack](docs/images/server-rack.jpg) ### Nodes The k8s cluster consists of the following nodes: | Name | Role | Model | Category | CPU | RAM | Storage | |-----------|---------------|-------------------------|-----------------|------------------|-------|--------------| | `gandalf` | Control Plane | EliteDesk 800 G3 Mini | hobbit-md-i5 | Intel i5-7500t | 16GB | 256GB NVMe | | `sam` | Worker | EliteDesk 800 G3 Mini | hobbit-md-i5 | Intel i5-7500t | 16GB | 256GB NVMe | | `pipin` | Worker | EliteDesk 800 G3 Mini | hobbit-sm-i3 | Intel i3-6100T | 16GB | 120GB NVMe | | `merry` | Worker | EliteDesk 800 G3 Mini | hobbit-sm-i3 | Intel i3-6100T | 16GB | 120GB NVMe | | `gollum` | Worker | Lenovo G400s Laptop | hobbit-bg-i7 | Intel i7-3612QM | 16GB | 1TB Sata SSD | ## Software The cluster runs a variety of software, from infrastructure components to user-facing applications. ### Apps | Application | Description | | ------------------------------------------------------------------------ | --------------------------------------------------------------------------- | | [`flash-slothmore`](https://service.berlin.de/) | A bot that crawls the Berlin Service Portal to find available appointments. | | [`hello-from-gondor`](https://hello.from-gondor.com) | Simple dashboard with basic cluster metrics. | | [`linkwarden`](https://docs.linkwarden.app/) | A self-hosted bookmark and link management system. | | [`pi-hole`](https://pi-hole.net/) | A network-wide ad blocker doubling as the LAN DNS server | | [`speedtest-tracker`](https://github.com/alexjustesen/speedtest-tracker) | A tool to track internet speed over time. | ### Infrastructure | Component | Description | | ------------------------------------------------------------------------------------------------ | ------------------------------------------------- | | [`cert-manager`](https://cert-manager.io/docs/) | Manages TLS certificates for the cluster. | | [`cloudnative-pg`](https://cloudnative-pg.io/) | Manages PostgreSQL clusters in Kubernetes. | | [`ingress-nginx`](https://kubernetes.github.io/ingress-nginx/) | Ingress controller for external access. | | [`internal-dns`](https://github.com/kubernetes-sigs/external-dns/) | An instance of external-DNS configured acting as a local DNS using Pi-hole as the DNS server. | | [`k8s-dashboard`](https://kubernetes.io/docs/tasks/access-application-cluster/web-ui-dashboard/) | Kubernetes dashboard for monitoring the cluster. | | [`longhorn`](https://longhorn.io/docs/) | Distributed block storage for persistent volumes. | | [`metallb`](https://metallb.universe.tf/) | Bare-metal load balancer for Kubernetes. | | [`onepassword`](https://developer.1password.com/docs/connect) | 1Password integration for managing secrets. | | [`renovate`](https://docs.renovatebot.com/) | Automated dependency updates. | | [`flux-system`](https://fluxcd.io/docs/) | The GitOps operator that powers the cluster. | | [`gatus`](https://github.com/TwiN/gatus) | Monitoring dashboard with the status of apps. | #### One Chart to rule them all This project uses a custom-made Helm chart called [`one-chart`](https://github.com/josimar-silva/homelab/pkgs/container/homelab%2Fone-chart). This chart is designed to be flexible and reusable, and it is used to deploy all the applications that do not have a dedicated Helm chart available. #### PostgreSQL Cluster Chart This project includes a custom Helm chart for deploying PostgreSQL clusters using CloudNativePG, located at `charts/postgresql-cluster`. ## Network The network is segmented into multiple VLANs to provide security and isolation between different types of traffic. The firewall is managed by OPNsense, which is running on a dedicated appliance. All the nodes in the Kubernetes cluster are connected to an isolated VLAN. `metallb` is used to provide LoadBalancer services for the applications. `internal-dns` provides name resolution for the services in the LAN by propagating the name records to Pi-hole. ## Storage Persistent storage is provided by `longhorn`. `longhorn` is a distributed block storage system that provides persistent volumes for stateful applications. For backups, a [QNAP TS-453E](https://www.qnap.com/en/product/ts-453e) NAS is used as an NFS share. Longhorn is configured to use this NFS share to back up all the persistent volumes of the cluster. ## Secret Management Secrets are managed using `onepassword` and the 1Password Connect Operator. The operator syncs secrets from a 1Password vault to Kubernetes secrets. This allows for a secure and centralized way to manage secrets. ## Acknowledgements This project would not have been possible without the amazing content produced by the homelab community. I would like to express my gratitude to the following individuals for been a great source of information and inspiration: - [Mischa Van den Burg](https://mischavandenburg.com/) - [GitHub](https://github.com/mischavandenburg/homelab) - [Techno Tim](https://technotim.live/) - [Christian Lempa](https://www.youtube.com/@christianlempa) - [Dave's Garage](https://www.youtube.com/@DavesGarage) - [Jeff Geerling](https://www.youtube.com/@JeffGeerling) - [Raid Owl](https://www.youtube.com/@RaidOwl) - [Home Network Guy](https://www.youtube.com/@homenetworkguy) - [Hardware Haven](https://www.youtube.com/@HardwareHaven) The ease with which I was able to set up this Kubernetes cluster, compared to my first NAS build over a decade ago, is a testament to the quality of the content and the collaborative spirit of the homelab community. -------------- #### *References* - [Kubernetes](https://kubernetes.io/) - [Talos OS](https://www.talos.dev/) - [FluxCD](https://fluxcd.io/) - [Renovate](https://www.mend.io/free-developer-tools/renovate/) - [one-chart](https://github.com/josimar-silva/homelab/tree/main/charts/one-chart)
